All Categories  > Monitors & Projectors  > Touchscreen Displays  > Elo 1525C 15" Touchmonitor
Elo 1525C 15" Touchmonitor

Elo 1525C 15" Touchmonitor

Mfg. Part: E386957  |  CDW Part: 1074167  |  UNSPSC: 43211903
Log On to Email this Page or
Add to Favorites.




15" CRT Touch Display, iTouch, Serial and USB, Beige
Main Features
Qty
$356.99
Advertised Price
Lease Option
Leasing
Please see cdw.com/leasing for more information.
($11.63 /month)
$69.99
Advertised Price
Recommended Warranty: 2 Extra Years Replacement Extended Warranty $201-$400  |  See all warranties

Availability:
Availability
Call for availability.
Call
Product Overview
Technical Specs
Warranties and Services
Product Overview Elo 1525C 15" Touchmonitor
Main Features
  • 15" CRT Touch Display
  • iTouch
  • Serial and USB
  • Beige
For delivering the best possible optics on a touch CRT, there is nothing better than Elo's unique iTouch touch-on-tube technology. No overlay means 100% of the brightness, picture quality, and color purity are preserved, with up to 80% less reflection than the competition. The touch is super sensitive, drift free and extremely precise as you are touching even closer to the image. If you want a touch CRT, you need to look no further.
Technical Specifications Elo 1525C 15" Touchmonitor
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Dimensions & Weight
Depth: 15.2 in
Height: 12.9 in
Weight: 28.7 lbs
Width: 14.3 in
Display
Projector Monitor Features: iTouch Surface Wave
Display (Projector)
Diagonal Size: 15 in
Dot Pitch Pixel Pitch: 0.28 mm
Form Factor: Desktop
Interface: VGA (HD-15)
Max H-Sync Rate: 70 kHz
Max Resolution: 1024 x 768
Max V-Sync Rate: 160 Hz
Signal Input: VGA
Technology: CRT
Type: Display
V-Sync Rate at Max Res.: 85 Hz
Video Bandwidth: 67 MHz
Header
Compatibility: PC
Manufacturer: Elo TouchSystems
Model: 1525C
Packaged Quantity: 1
Product Line: Elo Entuitive 3000 Series
Input Device
Movement Detection Technology: Surface acoustic wave
Type: Touch-screen
Interface Provided
Connector Type: 15 pin HD D-Sub (HD-15)
Interface (Output): VGA
Qty: 1
Miscellaneous
Compliant Standards: CE , CISPR 22 Class B , cUL , DDC/CI , FCC , MPR II , Plug and Play , TUV GS , UL
Service
Support Details Full Contract Period: 2 years
Support Details Type: Limited warranty
Service & Support
Type: 2 years warranty
Video Input
Analog Video Signal: RGB
TV Tuner Presence: No
Audio Output
Type: None
Environmental Parameters
Humidity Range Operating: 10 - 90%
Max Operating Temperature: 104 °F
Min Operating Temperature: 32 °F
Power Device
Form Factor: Internal
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Power Consumption Operational: 70 Watt
Video Output
Type: None
